Rainwater Harvesting Services
Nature of work: Designing, Installing, and Maintaining Rainwater Harvesting Systems
Scope of Work
- Evaluate rooftop or ground area for water collection potential
- Analyze soil percolation and groundwater table
- Determine rainfall data and daily water demand
- Roofwater collection system with PVC/GI pipelines
- First flush mechanism and filtration unit
- Recharge pit / borewell / storage tank integration
- Overflow and drainage planning
- Supply of required pipes, filters, chamber lids, sand, gravel, cement, and tanks
- Earth excavation, pit construction, brickwork, plastering, and chamber formation
- Plumbing and connection of pipeline from roof outlet to filtration
- Fitment of silt chamber, filter unit, and recharge borewell or storage tank
- Testing of water flow and filter function
- Sealing and final finishing of chambers
- One-time water collection testing during rains
- System handover with layout drawing
- Annual Maintenance Contract (AMC) option available
Technical Specifications (Typical System)
Technical Specifications (Typical System)
| Component | Details |
|---|---|
| Pipe Material | UPVC / CPVC / GI as per site requirement |
| Filter Type | Vee Wire Single Screen Filter |
| Recharge Pit Size | 3M × 3M × 3M (customizable) |
| Silt Chamber | Brickwork with cover |
| First Flush System | Manual |
| Capacity Handled | Up to 1,00,000 Litres/year per system |
Documentation Provided to Client
- Layout drawing
- Maintenance guide
- Work completion certificate
- AMC proposal (optional)
Tools & Equipment Used
- Earth cutter / digger
- Masonry tools
- Plumbing kit
- Water flow meter (for testing)
Past Work Experience
| Project / Client | Location | Year | Status |
| Mahavir Solitaire | Kandivli | 2024 | Completed |
| Dhanashree Mall | Thane | 2024 | Completed |
| Ajmera Boulevard | Malad | 2025 | Completed |
